1080P Endoscope Camera
Product Introduction
This is a 1080P high-definition resolution endoscope camera. The diameter of the product is only 4mm. It can penetrate into various small and difficult-to-observe spaces, presenting clear and detailed internal images to users.
Core parameters
-
Resolution:
Reach 1920×1080, that is, 1080P high-definition resolution, which can clearly present the subtle structure and texture of the observed object.
-
Lens parameters: The lens has good optical performance and a field of view of 85. It can obtain a wider field of view in a limited space while ensuring that the image edge is not distorted. The depth of field range is 30-80mm.
-
Image sensor:
The high-performance image sensor has the characteristics of high sensitivity and low noise. It can capture clear images even in low-light environments, which improves the adaptability of the device under complex light conditions.
Product advantages
High cost performance:
Compared with the same type of high-definition endoscope products, this 1080P endoscope camera has a more reasonable price while ensuring excellent performance, providing users with a cost-effective choice and reducing the cost of use.
01
Strong reliability:
The product adopts high-quality materials and advanced manufacturing technology, and undergoes strict quality inspection to ensure stable operation in various complex environments. It has high reliability and durability, reducing the losses caused by equipment failure.
02
Easy operation:
The design is humanized, and the operation interface is simple and easy to understand. Even first-time users can quickly get started and easily complete various operations, which improves work efficiency.
03
Customized service:
Customized solutions can be provided according to the special needs of different users, such as customized probes of specific sizes, special function software, etc., to meet a variety of application scenarios.
04
product Parameter(specification)
|
Module No. |
EZ-EN40S-1080P |
|
Sensor Type |
1/7.25" |
|
Sensitivity |
1.0 V/(Lux-sec) |
|
Pixel Size |
1.4 μ m x 1.4μ m |
|
Video Stream Fomat |
MJPG ,YUY2 |
|
Max Resolution |
1920X1080 |
|
Maximum Image Transfer Rate |
MJPG: 640X480 (20fps) 1280X720 (20fps) 1920X10800(15fps) YUY2: 640X480 (20fps) 1280X720 (20fps) 1920X1080(15fps) |
|
S/N Ratio |
38.3dB |
|
Dynamic Range |
73DB |
|
Min Lux |
0.03Lux |
|
Lens Construction |
3P+IR |
|
FOV |
85° |
|
Relative Illumination (Sensor) |
55% |
|
TV Distortio |
<-1% |
|
Work Voltage |
3.3V |
product feature and application
Medical field:
Otolaryngology: It can penetrate into the ear canal, nasal cavity, throat and other parts to check inflammation, polyps, foreign bodies, etc., and assist doctors in making accurate diagnoses.
Oral medicine: used to observe caries and pulp lesions inside teeth, as well as the health of oral mucosa, to provide a basis for the treatment of oral diseases.
Gynecology: Checking the cervix, vagina and other parts to help doctors find lesions is an important tool for screening and diagnosis of gynecological diseases.
Industrial testing:
Auto repair: It can detect carbon deposits, piston wear, pipe blockage and other problems inside the car engine. It can also be used to check parts that are difficult to observe directly, such as car air-conditioning evaporator and three-way catalytic converter, to provide accurate fault information for car repair.
Electronic manufacturing: During the production of circuit boards, check the quality of the solder joints, the connection of the circuit boards, and whether the installation of tiny components is correct to ensure the quality and performance of electronic products.
Pipeline testing: It is used to detect corrosion, scaling, leakage and other problems inside various industrial pipelines, such as water pipes, gas pipes, oil pipes, etc., to find hidden dangers in time and ensure the normal operation of the pipeline system.
Other fields:
Security inspection: It can be used to check hidden corners and ventilation ducts of buildings, to check safety hazards and prevent criminal activities.
Cultural relic restoration: During the restoration process, the internal structure and damage of the cultural relic are observed with the help of the endoscope camera, providing detailed information for the restoration work and ensuring the accuracy and safety of the restoration work.
Hot Tags: 1080p endoscope camera, China 1080p endoscope camera manufacturers, suppliers, factory
